A300BX-FB | OEM Peristaltic Pump | Closed-Loop | 24V Brushless DC | Models to 1700 mL/min

SKU: A302BX-150-FB

Description

The A300BX-FB is a durable pump designed for fixed output consistency. It features a high-performance, brushless DC motor, paired with our closed loop, PID (proportional–integral–derivative) controller that continuously regulates output to prevent under or over dosing. This advanced control feature makes the pump an ideal solution for precision dosing, dispensing, and mixing applications.

A300 Series pumps can be ordered to utilize Performance Class Tubing (A301 Models) or Premium Class Tubing (A302 Models), providing the flexibility to perform in a wide range of applications.

Features and Benefits

  • Compensates for variations in voltage, fluid viscosity and tubing condition
  • Adjustments made every 10 milliseconds for high consistency
  • Wide range of adjustable, fixed flow rates with included potentiometer
  • Ideal solution for multi-head filling and proportional mixing stations
  • Convertible to alternate tubing class usage with change of Roller Assembly
  • Accepts continuous tubing for clean fluid paths
  • Long-lasting brushless DC motor
  • Available in a range of standard colors
  • Up to 25 psi working pressure
  • Made in USA
    Flow Rates
    Flow Rates by RPM Class and Tube Bore (mL/min)
    RPM Class Speed Setting Tube Bore
    1/4" 3/16" 1/8"
    600 Max 1951 1190 566
    Min 335 204 97
    300 Max 1154 704 335
    Min 207 126 60
    150 Max 468 285 136
    Min 91 56 26

    NOTES TO FLOW CHART:

    Flow rates are for guidance purposes only and are based upon pumping ambient temperature (22°C/72°F) water at zero pressure and zero lift. Rates may increase/decrease based upon numerous factors including: motor variances, tubing characteristics, fluid viscosity, lift height, pressure and number of rollers.

    Specifications
    SPECIFICATIONS
    Pump Series A301BX-FB | A302BX-FB
    Tubing Class Performance | Premium
    Motor Type Brushless DC (42mm)
    Operating Voltage 24V
    Rated Current 2.0A
    Duty Cycle Continuous
    Est. Motor Life 5,000+ Hours
    Max. Outlet Pressure 25 psi
    MATERIALS OF CONSTRUCTION
    Pump Head Polycarbonate
    Roller Material MoS2 Filled Nylon
    Rotor Material CRS - Zinc Plated
    DIMENSIONS

     Step File
